Finolex Optical Fiber Cables for High-Bandwidth Data Transmission

FAST CONNECTOR Price : 22 INR/Piece Minimum Order Quantity : 100 Product Type : Fast Connector (Field Assembly Optical Connector) Conductor Type : Other, Singlemode/Multimode compatible Length : Standard 60 mm Application : Other, FTTH (Fiber To The Home), Telecommunication, Data transmission, CATV Locking Type : Pushpull lock Usage & Applications : Quick fiber optic terminations in the field, last mile connectivity Material : ABS plastic, Ceramic ferrule Install Type : Field assembly, toolless Diameter : 2.0 x 3.0mm (cable) Voltage : Other, 250V Conductor Shape : Round Jacket Color : Blue Storage Temperature : 40°C to +75°C Features : Easy installation, low insertion loss, reusable and compact design Color : Blue Dimension (L*W*H) : 60mm x 10mm x 8mm Rated Temperature : 40°C to +75°C Cable Type : FTTH Drop Cable, 2.0 x 3.0mm Jacket Material : Other, Plastic ABS material Operating Temperature : 40°C to +75°C Weight : Approx. 5g per piece Size : Standard SC fast connector dimensions Connector Color : Blue Conductor Material : Other, Optical Fiber Core Number : Single core Shield Material : None (Nonmetallic) Core Material : Glass Fiber Insulation : Ceramic sleeve insulation Tensile Strength : 50N Insulation Material : Other, High precision ceramic ferrule Number of Conductor : 1 Impedance : 50 Ohm (typical for fiber optic) Dielectiric Strength : 2kV Armored Material : Nonarmored

FM 45 CONNECTOR Price : 700.0 INR/Piece Minimum Order Quantity : 10 Product Type : FM 45 Connector (RJ45) Conductor Type : Other, Solid or Stranded Length : Standard RJ45 plug size Application : Other, Networking, ethernet cables, telephone connections Locking Type : Snapin latch Usage & Applications : LAN networking, internet, data and voice transmission Material : Polycarbonate, Copper Install Type : Crimp type Diameter : Fits 2426 AWG cables Voltage : Other, 250V AC Conductor Shape : Round Jacket Color : Other, Clear Storage Temperature : 20°C to 80°C Features : Durable, easy installation, corrosion resistant, secure fit Color : Transparent Dimension (L*W*H) : 21mm x 11.6mm x 8mm Rated Temperature : 10°C to 60°C Cable Type : CAT5, CAT5e, CAT6, CAT6e UTP/STP Jacket Material : Other, Polyvinyl Chloride (PVC) Operating Temperature : 10°C to 60°C Weight : Approx 2g each Size : Standard RJ45 Connector Color : Transparent Conductor Material : Copper Core Number : 8P8C Shield Material : Unshielded Core Material : Copper Insulation : Polycarbonate insulated Tensile Strength : ≥ 20N Insulation Material : Other, Polycarbonate Number of Conductor : 8 Impedance : 100 Ohm Dielectiric Strength : 1000V AC/min

patch cord ftth Minimum Order Quantity : 10 Product Type : FTTH Patch Cord Conductor Type : Other, Singlemode or Multimode (customizable) Length : Customizable (available in 1m, 2m, 3m, etc.) Application : Other, FTTH (Fiber to the Home), data centers, telecommunication networks, CATV Locking Type : Standard push/pull for SC/LC connectors Usage & Applications : FTTH, CATV, network cabling, indoor/outdoor networks Material : PVC/LSZH Install Type : Plug and Play Diameter : 2.0mm or 3.0mm Voltage : Other, N/A (Passive Optical Component) Conductor Shape : Round Jacket Color : Yellow Storage Temperature : 25C to +85C Features : Low insertion loss, high return loss, excellent durability, stable performance. Color : Yellow (standard) or as required Dimension (L*W*H) : Varies with length and connector type Rated Temperature : 20C to +70C Cable Type : Singlemode or Multimode optical fiber Jacket Material : Other, PVC or LSZH Operating Temperature : 20C to +70C Weight : Approx. 18g/m Size : Standard (customizable length) Connector Color : Yellow (as per image) Conductor Material : Other, Optical Fiber (Glass) Core Number : 1 or 2 Shield Material : N/A (Unshielded optical fiber) Core Material : Glass Fiber Insulation : PVC/LSZH Tensile Strength : 80 N (Short Term) Insulation Material : Other, PVC or LSZH (Low Smoke Zero Halogen) Number of Conductor : 1 or 2 (Simplex or Duplex) Impedance : N/A (Optical Signal) Dielectiric Strength : 15 kV/mm Armored Material : Optional, Steel Tube if armored

Finolex Fiber Cleaver Price : 1500 INR/Piece Minimum Order Quantity : 10 Product Type : Fiber Cleaver Length : Portable dimension, standard for handheld Application : Other, Fiber optic cable termination; Field installation; Maintenance Locking Type : Blade locking lever Usage & Applications : FTTH, CATV, fiber research labs, fibre optic cable installation Material : Aluminum Alloy, precision steel blade Install Type : Handheld, portable Diameter : Suitable for 0.25 mm 0.9 mm fiber coatings Voltage : Other, Not required (manual tool) Storage Temperature : 20°C to +70°C Features : High precision blade; Single fibre cleaving; Compact design; Long blade life; Easy operation Color : Black Dimension (L*W*H) : 56 mm x 52 mm x 42 mm Rated Temperature : 10°C to +60°C Cable Type : Singlemode and multimode fiber Operating Temperature : 10°C to +60°C Weight : Approx. 350g Size : Compact handheld
